Fujitsu ETERNUS AF Series Site Planning Guide

● 3.5" Type Drive Enclosure
The diagrams below show the dimensions of a 3.5" type drive enclosure.
The dimension values do not include any protruding parts (approximation).
Figure 4 3.5" Type Drive Enclosure Dimensions
560mm88mm
482mm
Top
Front
Side
Rack Dimensions
The following diagrams show the dimensions of a 19-inch rack. The dimension values do not include any pro-
truding parts (approximation).
1. ETERNUS DX Installation
Rack Dimensions
21
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
