Fujitsu ETERNUS AF Series Site Planning Guide

■
19-inch Racks (for GS21 2600/2400, 1800mm)
For specification information that is required for securing a rack, refer to Figure 19 under "
Installation Methods"
(page 33).
Figure 9 19-inch Rack (for GS21 2600/2400, 1800mm) Dimensions
Top
Front RearSide
Bottom
1,800mm
1,110mm
700mm
1. ETERNUS DX Installation
Rack Dimensions
26
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
