ETERNUS DX8700 S3
The following table shows the installation specifications of the ETERNUS DX8700 S3
.
Table 2 ETERNUS DX8700 S3 Installation Specifications
Item ETERNUS DX8700 S3
Dimensions
(W ´ D ´ H)
Frontend enclosure
482 ´ 795 ´
222 mm (5U)
Controller enclosure
482 ´ 809 ´
133mm (3U)
Drive enclosure 2.5" type
482 ´ 540 ´ 88mm (2U)
3.5" type
482 ´ 560 ´ 88mm (2U)
Power distribution unit
(*1)
Horizontal type
485 ´ 280 ´
43mm ´ 2 (2U) (*2),
485 ´ 123 ´ 44mm ´ 2 (2U) (*3)
Vertical type
39 ´ 382 ´ 440mm ´ 2 (*4)
Maximum weight Frontend enclosure 64kg
Controller enclosure 54kg
Drive enclosure (*5) 2.5" type 35kg
3.5" type 35kg
Power distribution unit
(*1)
Horizontal type
(6.0kg) ´
2 (*2),
(3.0kg) ´ 2 (*3)
Vertical type
(5.0kg) ´
2 (*4)
Power Voltage AC 200 – 240V
Phase Single
Frequency 50Hz/60Hz
Maximum power con-
sumption
Frontend enclosure 450W (480VA)
Controller enclosure 1,200W (1,220VA)
Drive enclosure (*5) 2.5" type 430W (440VA)
3.5" type 340W (350VA)
Maximum heat genera-
tion
Frontend enclosure 1,630kJ/h
Controller enclosure 4,330kJ/h
Drive enclosure (*5) 2.5" type 1,600kJ/h
3.5" type 1,300kJ/h
Maximum amount of ex-
haust air
Frontend enclosure
7.0m
3
/min
Controller enclosure
6.2m
3
/min
Drive enclosure (*5) 2.5" type
4.0m
3
/min
3.5" type
4.0m
3
/min
1. ETERNUS DX Installation
Installation Specifications
12
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
