19-inch Racks
■
19-inch Racks (with Standard Door, 2000mm)
The following table shows the installation specifications of the 19-inch racks (with standard door, 2000mm).
Table 4 19-inch Rack (with Standard Door, 2000mm) Installation Specifications
Item
Specification
Base rack Expansion rack
Dimensions (W ´
D ´ H) 700 ´ 1,050 ´ 2,000mm
700 ´ 1,272 ´ 2,000mm (including anti-tipping stabilizer)
Maximum weight 140kg 115kg
Service area Refer to Figure 10
in "Installation Area" (page 29).
Number of units 42U
■
19-inch Racks (with a DX8000 Series Dedicated Door, 2000mm)
The following table shows the installation specifications of the 19-inch racks (with a DX8000 series dedicated
door, 2000mm).
Table 5 19-inch Rack (with a DX8000 Series Dedicated Door, 2000mm) Installation Specifications
Item
Specification
Base rack Expansion rack
Dimensions (W ´
D ´ H) 700 ´ 1,090 ´ 2,000mm
700 ´ 1,272 ´ 2,000mm (including anti-tipping stabilizer)
Maximum weight 155kg 125kg
Service area Refer to Figure 11
in "Installation Area" (page 29).
Number of units 42U
■
19-inch Racks (for GS, 1400mm)
The following table shows the installation specifications of the 19-inch racks (for GS, 1400mm).
Table 6 19-inch Rack (for GS, 1400mm) Installation Specifications
Item Specification
Dimensions (W ´
D ´ H) 700 ´ 1,050 ´ 1,400mm
Maximum weight 108kg
Service area Refer to Figure 12
in "Installation Area" (page 29).
Number of units 28U
1. ETERNUS DX Installation
Installation Specifications
16
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
