Fujitsu ETERNUS AF Series Site Planning Guide

■
19-inch Racks (with Standard Door, 2000mm)
For specification information that is required for securing a rack, refer to Figure 15 under "Installation Methods
"
(page 33).
Figure 5 19-inch Rack (with Standard Door, 2000mm) Dimensions
Front
Rear
Bottom
2,000mm
1,050mm
700mm
Side
Top
1. ETERNUS DX Installation
Rack Dimensions
22
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
