● 19-inch Racks (for GS21 2600/2400, 1800mm)
Figure 19 Floor Dimensions of the Rack (of 19-inch Racks (for GS21 2600/2400, 1800mm))
Caster
Leveling feet
Cable slot
Load Bearing Capacity for Floors
Make sure that the following relationship between the load bearing capacity of the floor and the weight of the
ETERNUS DX is maintained.
(Load bearing capacity of the floor)
> (ETERNUS DX weight ¸ Installation area that includes service areas)
If the condition above is not satisfied, additional measures are required to ensure sufficient load bearing capaci-
ty.
Contact your installation contractor for details about the necessary measures that must be taken.
1. ETERNUS DX Installation
Installation Environment
37
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
