Fujitsu ETERNUS AF Series Site Planning Guide

■
19-inch Racks (with a DX8000 Series Dedicated Door, 2000mm)
For specification information that is required for securing a rack, refer to Figure 16 under "Installation Methods
"
(page 33).
Figure 6 19-inch Rack (with a DX8000 Series Dedicated Door, 2000mm) Dimensions
Top
Front Rear
Side
Bottom
2,000mm
1,090mm
700mm
1. ETERNUS DX Installation
Rack Dimensions
23
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
