Storage System Dimensions
■
Frontend Enclosure Dimensions
The following diagrams show the dimensions of a frontend enclosure.
The dimension values do not include any protruding parts (approximation).
Figure 1 Frontend Enclosure Dimensions
795mm
222mm
482mm
Top
Side
1. ETERNUS DX Installation
Storage System Dimensions
18
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
