Power Distribution Units (AC200-240V, Horizontal Type) (Only for Regions other than the
EMEIA, Central American, and Caribbean Regions)
There are 16 outlets and two inlets.
The exterior types that are available for
power distribution units (AC200-240V, horizontal type) are shown in
Figure 20 and Figure 21.
Figure 20 Power Distribution Unit (AC200V, Horizontal Type)
Sixteen outlets
Two inlets
Figure 21 Power Distribution Unit (AC200V, Horizontal Type)
Sixteen outlets
Two inlets
Table 14 Power Distribution Unit (AC200-240V, Horizontal Type) Specifications
Outlet Inlet
Voltage rating/current
rating
Socket type
(Socket)
Plug type
Socket type
(Socket)
Cable length
IEC60320 C13
NEMA L6-30P NEMA L6-30R 4.0m Rating: 250V 30A
(Normal usage rating:
24A [12A ´ 2])
1. ETERNUS DX Installation
Outlet/Socket Specifications
41
FUJITSU Storage ETERNUS DX8100 S3/DX8700 S3/DX8900 S3 Hybrid Storage Systems
Site Planning Guide
Copyright 2020 FUJITSU LIMITED
P3AM-9422-13ENZ0
