RX200 S6 Service Supplement 45
5 Appendix
5.1 Board layout
I The board layout of the system board is described in the "System Board
D3031 for PRIMERGY RX200 S6 Technical Manual".
You will find the part numbers of the cables in the cabling plans (see the
Appendix of the Options Guide RX200 S6).
5.1.1 LED board
Part number: SNP:A3C40102647
Figure 21: LED board
1 Front panel cable
