48 Service Supplement RX200 S6
Appendix
5.1.4 Power-distribution module
Part number: S26361-D3068-A100
Figure 24: Power-distribution module
1 Plug P3 to connector PWR CTRL on the system board
2 Plug P1 to connector PWR on the system board
3 Plug P2 to power connector on the HDD backplane
1
2
0
