46 Service Supplement RX200 S6
Appendix
5.1.2 HDD backplane 6x HDD modules
Part number: SNP: A3C40102618
Figure 22: HDD backplane 6x HDD modules
1 DVD cable power
2 SAS cable for channel "B"
3 Power cable
4 SAS cable for channel "A"
1 2
0
3
