28 Options Guide TX200 S6
Preparation
4.1 Floorstand model
4.1.1 Opening the server
Ê Terminate all applications and shut down the server correctly.
Ê If your operating system has not switched off the server, press the On/Off
button.
Ê Pull all power cords out of the power outlet.
Ê Unlock the server and remove the key.
Figure 2: Opening the server
Ê Pull the locking lever as far as it will go (1). This pushes the side cover
backward (2).
Ê Remove the side cover (3).
/
