TX200 S6 Options Guide 101
11 Conversion from a floorstand
model to a rack model
V CAUTION!
Follow the safety instructions in the chapter "Safety instructions" on
page 19.
Figure 83: Removing the anti-tilt bracket
Ê Remove the two knurled screws (1).
Ê Lift the server slightly and remove the anti-tilt bracket.
I The anti-tilt bracket is no longer required.
Ê Open the server as described in the chapter "Preparation" on page 27.
Ê Remove the front cover as described in the section "Removing the front
cover" on page 29.
I The front cover is no longer required.
