46 Options Guide TX200 S6
Processors
Ê Place the processor in the socket with great care.
V CAUTION!
Do not bend the spring contacts of the processor socket. Never touch
the underside of the processor. Even light contaminants, such as oil
from human skin, can destroy the processor or impair its functionality.
Figure 17: Locking the processor
Ê Close the processor holder (1).
Ê Lock the processor in the socket by returning the spring clip to its original
position (2).
Ԙ
ԙ
