User’s Guide FUJITSU PSWITCH
December/2018 171
Top View
Screws Location
PSWITCH
2048T/P
Side on PSU/FAN
Side on Ports
Left side4 places
Right side4 places
Side on PSU/FAN9 places
Side on Ports6 places
Total23 places
PSWITCH
4032P
Side on PSU/FAN
Side on Ports
Left side3 places
Right side3 places
Side on PSU/FAN6 places
Side on Ports6 places
Total18 places
2) Remove the top cover of the switch.
2. Remove the battery
