Fujitsu ScanSnap S1500M User Manual

Actions (for Windows Users)
150
Without Using the Quick Menu
1. Select [Scan Button Settings] from the Right-Click Menu.
For details about the Right-Click Menu, refer to "Right-Click Menu" (page 70).
D The ScanSnap setup dialog box appears.
2. In the [Application] drop-down list in the [Application] tab, select
[CardMinder].
3. Click the [OK] button to close the ScanSnap setup dialog box.
To disable the Quick Menu, you need to clear the [Use Quick Menu] check box in the ScanSnap
setup dialog box.
For details about how to perform scanning without using the Quick Menu, refer to "Without Using
the Quick Menu" (page 79).
It is recommended that you select [Automatic resolution] or [Best] for [Image quality] in the
[Scanning] tab of the ScanSnap setup dialog box. ScanSnap Manager cannot link with
CardMinder when [Image quality] is set to [Excellent].
ScanSnap Manager also links with [CardMinder] when you select:
z [CardMinder] from the [Profile] drop-down list of the ScanSnap setup dialog box
z [CardMinder] from the Left-Click Menu

Fujitsu ScanSnap S1500M Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
Bundled software	Cardiris 3.6, Adobe Acrobat 8 Professional, ABBYY FineReader
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	292 x 159 x 158 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.5 x 6.3 x 6.2 \
Minimum storage drive space	2440 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	4.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	3000 g
