Fujitsu ScanSnap S1500M User Manual

How to Perform a Scan (for Windows Users)
72
How to Perform a Scan
This section explains how to perform scanning with the ScanSnap.
■ Preparation
1. Turn on the computer.
D The ScanSnap Manager icon appears on the taskbar when Windows starts up.
z If the ScanSnap Manager icon is not displayed, select [Start] menu → [All
Programs] → [ScanSnap Manager] → [ScanSnap Manager] to start up ScanSnap
Manager. Normally, ScanSnap Manager is registered under [Startup] when installed so
its icon is displayed on the taskbar when Windows starts.
z When ScanSnap Manager is not registered under [Startup], register ScanSnap
Manager in the following procedure:
1. Select [Help] → [Preferences] in the Right-Click Menu.
D [ScanSnap Manager - Preferences] dialog box appears.
2. In the [Auto Startup] tab, select the [Start up ScanSnap Manager when you log on]
check box.
z In Windows 7, the ScanSnap Manager icon is displayed in the menu which appears
when you click on the taskbar.
For details about how to display the ScanSnap Manager icon on the taskbar, refer
to "ScanSnap Manager Icon and Operations" (page 69).

Fujitsu ScanSnap S1500M Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
Bundled software	Cardiris 3.6, Adobe Acrobat 8 Professional, ABBYY FineReader
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	292 x 159 x 158 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.5 x 6.3 x 6.2 \
Minimum storage drive space	2440 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	4.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	3000 g
