Fujitsu ScanSnap S1500M User Manual

Configuring ScanSnap Manager (for Windows Users)
87
■ How to Configure Scan Settings
You can configure scan settings in the ScanSnap setup dialog box depending on your
intended use in the following procedure.
1. Select [Scan Button Settings] from the Right-Click Menu.
For details about the Right-Click Menu, refer to "Right-Click Menu" (page 70).
D The ScanSnap setup dialog box appears.
2. Click the [Detail] button to switch to the detail view mode.
zUsing the Quick Menu
zWithout using the Quick Menu
You can also open the ScanSnap setup dialog box by the following ways:
z Double-click the ScanSnap Manager icon .
z Press [Ctrl], [Shift], and [Space] keys simultaneously.
The ScanSnap setup dialog box retains the display status from the last time the ScanSnap
was used. For example, if it was closed in detail view mode, the dialog box is displayed in
detail view mode next time you open it.
Outline view Detail view
Outline view Detail view

Fujitsu ScanSnap S1500M Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
Bundled software	Cardiris 3.6, Adobe Acrobat 8 Professional, ABBYY FineReader
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	292 x 159 x 158 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.5 x 6.3 x 6.2 \
Minimum storage drive space	2440 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	4.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	3000 g
