Fujitsu ScanSnap S1500M

Cleaning the Inside of the ScanSnap
426
How to perform cleaning
1. Unplug the power cable from the AC outlet.
2. Pull the ADF release catch to open the ADF top section.
3. Clean the following locations with a cloth moistened with Cleaner F1.
z Do not use water or mild detergent to clean the inside of the ScanSnap.
z It may take a long time for Cleaner F1 to dry if an excessive amount is used. Moisten
the cloth with moderate quantity.
Wipe off the cleaner completely to leave no residue on the cleaned parts.
ADF release
catch
ADF top section
ADF paper chute (cover)
Pad assy
Idler roller (×4)
Glass (×2)
(including the one on the ADF
top section)
Pick roller
Ultrasonic sensor
(including the one on the ADF
top section)
Pick spring (metal part)
*gray part
