Fujitsu ScanSnap S1500M User Manual

Actions (for Windows Users)
216
6. Press the [Scan] button on the ScanSnap to start a scan.
D The [Scan to Mobile] dialog box appears on the computer when the scanning is
completed.
7. Connect to the computer from your mobile device.
For details about how to connect to the computer from your mobile device, refer to the
ScanSnap Connect Application User’s Guide (iOS).
D When the connection is established, the [Scan to Mobile] dialog box appears
showing the mobile device that is currently connected to the computer. Then, the
scanned image is sent to the mobile device.
z When you select the [Wait until the [Send] button is clicked] check box in the [Scan to
Mobile - Basic] dialog box, the [Send] button appears in the [Scan to Mobile] dialog box.
Click the [Send] button to send the image to the mobile device.
z For details about the features of ScanSnap Connect Application for mobile devices and
how to use it, refer to the ScanSnap Connect Application User's Guide (iOS).

Fujitsu ScanSnap S1500M Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
Bundled software	Cardiris 3.6, Adobe Acrobat 8 Professional, ABBYY FineReader
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	292 x 159 x 158 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.5 x 6.3 x 6.2 \
Minimum storage drive space	2440 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	4.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	3000 g
