How to Load Documents
34
7. Load the documents in the ADF paper chute (cover).
Load the documents face-down and top-first with their back facing you. Load the
documents so that they are not beyond the reference marks within the side guides.
z Do not leave more than 50 sheets (80 g/m² or 20 lb.) of ejected documents on the
stacker.
z Right-click the ScanSnap Manager icon on
the taskbar, and select [Scan Button Settings].
In the ScanSnap setup dialog box that appears,
click the [Detail] button, then select the
[Scanning] tab → [Option] button. If the [Set the
document with its face up] check box is selected
in the [Scanning mode option] dialog box, load
documents face-up and bottom edge first.
In Windows 7, the ScanSnap Manager icon
is displayed in the menu which appears when
you click on the taskbar.
Side guide

Fujitsu ScanSnap S1500M Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
Bundled software	Cardiris 3.6, Adobe Acrobat 8 Professional, ABBYY FineReader
Scan media weight	52 - 127 g/m²
Dimensions (WxDxH)	292 x 159 x 158 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.5 x 6.3 x 6.2 \
Minimum storage drive space	2440 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	4.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	3000 g
