Replacing the Pad Assy
434
5. Attach a new pad assy.
6. Close the ADF top section.
D It clicks when it returns to its original position.
7. Connect the power cable, and turn on the ScanSnap.
Confirm that the pad assy is attached properly. Otherwise, paper jams or other feeding
errors may occur.
ADF top section
ADF paper chute
(cover)
To Next Page
