Replacing the Pick Roller
438
5. Remove the sheet guide.
Hold the pickup tabs on both ends, and lift it up and away.
6. Rotate the bushing (left).
Sheet guide
Pickup tab
Pickup tab
Shaft
Bushing
Pick roller
