Replacing the Pick Roller
440
8. Remove the pick roller from its shaft.
D Pull out the shaft as you lift the retaining clip.
9. Attach a new pick roller on the shaft.
Insert the protrusion on the shaft into the slot.
Lifting the retaining clip with your fingernail may hurt or damage your fingernail.
Use a paper clip or something alike if you have trouble lifting it up.
Shaft
Pick roller
Retaining clip
Protrusion
Shaft
Pick roller
To Next Page
