Fujitsu ScanSnap S500 User Manual

2.1 Installing the Supplied Programs for ScanSnap
ScanSnap S500 Operator's Guide 19
Connecting ScanSnap
2
8. In the "ScanSnap Manager Setting 1" screen, specify the document loading method,
and click the "Next" button.
To load the document face down and upside down on the scanner, check the left radio but-
ton.
To load the document face up on the scanner, check the right radio button.
⇒ The next "ScanSnap Manager Setting 2" screen appears.
HINT
Depending on the selected item, the following programs are installed.
• Typical
"ScanSnap Manager", "ScanSnap Organizer" and "CardMinder" are installed including
their manuals.
• Compact
"ScanSnap Manager" is installed including its manual.
• Custom
You can select the software and the manuals to install.
HINT
• You can change this setting after installation.
Refer to "- Set the documents with its face up" (page 66)" in the section "3.4
Changing Scan Settings" for more details.
• This screen will not appear when reinstalling the program. The settings before
the reinstallation remain.

Fujitsu ScanSnap S500 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 356 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	50 sheets
USB version	2.0
Standard interfaces	USB 2.0
Minimum system requirements	Windows 2000/ XP/ Vista
Scan media weight	52 - 127 g/m²
Power requirements	AC 100V - 240V, 50 / 60 Hz
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	2700 g
