Chapter 4
Peripheral Interfaces
Details on peripheral interfaces on the Stylistic ST5000 Tablet PC and/or Tablet Dock are described in this chapter.
The Stylistic ST5000 Tablet PC and Tablet Dock provide the following peripheral interfaces:
* Note that the system interface port allows you to connect the optional Stylistic ST5000 Tablet Dock.
Pin assignments for peripheral interfaces on the Stylistic ST5000 Tablet PC are given in the following sections.
DC Power Input 4
The DC power input connector connects to the AC adapter or auto adapter to power the Tablet PC. The DC power
input connector is a two-conductor connector with a center pin and sleeve. Pin assignments for this connector are
given in Table 4-2.
When a DC power source is connected to the DC power input on the Tablet PC, circuitry built into the Tablet PC
provides protection against reverse polarity and overvoltage.
Table 4-1. Peripheral interfaces
Interface Tablet PC Quantity Tablet Dock Quantity
DC Input connector 1 1
Wireless LAN port 1 --
IEEE 1394 jack 1 1
External Monitor port 1 1
Line Out jack -- 1
IrDA port 1 --
Infrared keyboard port 2 --
Universal Serial Bus (USB) 2.0 port 2 3
RJ-11 modem jack 1 --
RJ-45 LAN jack 1 1
Stereo headphone jack 1 --
Microphone jack 1 --
PC Card socket 1 --
Smart Card slot 1 --
SD/Memory Stick slot 1 --
System interface port* 1 1
Table 4-2. DC Power Input Connector Pin Assignments
Conductor Description Comments
Center Pin 16 Volts DC ±10%, 3.75 A (Hosiden part number HEC3900-01-010)
This connector is a EIAJ-RC5320A standard connector. S
Sleeve Ground
