System Power Hardware 49
DC Power Inputs 5
External DC power can be connected at two locations on the Tablet PC:
• DC power connector on the Tablet PC
• System interface connector (via Tablet Dock)
A DC power source connected to any of these inputs must provide 3.75 amps at a continuous DC voltage of 16 volts
±10%. Specifications for the DC input connectors on the Tablet PC and Tablet Dock are given below.
* This is the part number for the female DC input connector on the Tablet PC and the Tablet Dock.
Table 5-1. DC Input Connectors
Connector type EIAJ RC-5320A Type 5
Connector vendor Hosiden
Vendor part number* HEC3900-01-010
Pin assignments Center conductor: +16 VDC ±10%
Sleeve: ground
