PC Card Port 44
48 A19 A19 CBLOCK#
49 A20 A20 CSTOP#
50 A21 A21 CDEVSEL#
51 VCC VCC VCC
52 VPP2 VPP2 VPP2
53 A22 A22 CTRDY#
54 A23 A23 CFRAME#
55 A24 A24 CAD17
56 A25 A25 CAD19
57 VS2# VS2# CVS2
58 RESET RESET CRST#
59 WAIT# WAIT# CSERR#
60 RFU INPACK# CREQ#
61 REG# REG# CCBE3#
62 BVD2 SPKR# CAUDIO
63 BVD1 STSCHG# CSTSCHG
64 D8 D8 CAD28
65 D9 D9 CAD30
66 D10 D10 CAD31
67 CD2# CD2# CCD2#
68 GND GND GND
16-bit PC Card Interface
CardBus
Pin Memory-Only I/O & Memory
