IEEE 1394 Port 47
External Monitor Port
Table 4-12. External Monitor Port Pin Assignments
Pin Signal (KB) Host I/O
1RED
2 GREEN
3BLUE
4NC --
5 GND --
6 GND --
7 GND --
8 GND --
9 DDCVCC --
10 GND --
11 NC --
12 DDCDATA
13 HSYNC
14 VSYNC
15 DDCCLK
54 321
678910
11121315 14
