TIGHTENING TORQUES FOR GENERAL USE BOLTS AND NUTS
0-8
Tightening torque for flare nut for general purpose (Unit: N·m {kgf·m})
Tightening torque for air piping nylon tube for general purpose (DIN Type) (Unit: N·m {kgf·m})
Tightening torque for air piping nylon tube for general purpose (SAE Type) (Unit: N·m {kgf·m})
Pipe diameter
φ4.76 mm φ6.35mm φ8 mm φ10 mm φ12 mm φ15 mm
Tightening torque 17 {1.7} 25 {2.6} 39 {4.0} 59 {6.0} 88 {9.0} 98 {10.0}
Standard diameter 6 × 1 mm 10 × 1.25 mm 12 × 1.5 mm 15 × 1.5 mm
Tightening torque
20 {2.0 } 34 {3.5 } 49 {5.0 } 54 {5.5 }
Standard diameter 1/4 in. 3/8 in. 1/2 in. 5/8 in.
Tightening torque
13 {1.3 } 29 {3.0 } 49 {5.0 } 64 {6.5 }
+5.9
0
+0.6
0
+10
0
+1.0
0
+10
0
+1.0
0
+5
0
+0.5
0
+4
0
+0.4
0
+5
0
+0.5
0
+5
0
+0.5
0
+5
0
+0.5
0
