Model Menu (Common Functions)
＞
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
Wheel/Cycle Door
1．Select the switch to operate.
2．Select gear operation output function.
3．Select door operation output function.
4．Setting each rate and timing
Tap
Tap
Tap
SW direction
Tap the desired SW
Tap the function to operate the gear
Tap the function to operate the door
Gear down servo
rate setting
Time difference
between door
opening and
gear down
Time difference
between gear
down and door
closing
Time difference
between gear
up and door
closing
Time difference
from door
opening to
gear up
Gear down servo
speed setting
Set value
Door opening/
closing servo
speed setting
Door opening/
closing servo rate
setting
+(/,&237(5
$,53/$1(
*/,'(5
