FUTABA 32MZ-WC - Battery exchange

20
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
Batteryexchange
Battery
Battery removal clip
Battery connector
Note:
'HWDFKLQJWKHEDWWHU\ZKLOHWKHSRZHULVRQFDQFDXVH
GDWD\RXKDYHUHFHQWO\HGLWHGWREHORVW
1. Open the battery cover by sliding as shown in the
ÀJXUH
2. Pull out the Battery removal clip and slide out the
battery.
3. Remove the battery from the battery holder.
The battery holder can not be
removed from the transmitter.
Slide it to the position where the battery can
be held by the internal battery holder.
Battery holder
Battery
Battery removal clip
