FUTABA 7PX - MC Link (ESC Link)

Communication port.
Cover
Connecting ESC receiver
connector to the transmitter
Communication port.
Battery
140
Function
MC Link (ESC Link)
Home screen
Menu screen Accessory menu screen
Timer
This is a special function which allows Futaba motor controller (MC) data changes to be set
by the T7PX transmitter (MC960CR, MC950CR, MC851C, MC602C, MC402CR, etc.).
However, some data changes require a PC and Link software.
This function is used by connecting ESC directly to the transmitter.
Use the various optional servo extension cords according to the distance between the trans-
mitter and ESC.
MC Link (ESC Link)
-Also connect the battery at the ESC side.
Setup item (after it reads)
Read
Write
Reset
Data list
