Calibration
Steering and throttle correction can be applied. Use this function when a mechanical offset
has occurred for some reason.
Calibration
However, if correction was applied, it may be necessary to recheck the set values of all
the setup functions.
(Preparation)
Tap the [Wheel]. The neutral correction screen appears.
1
(Steering neutral adjustment)
After the wheel lightly to the left or right, tap the [Neutral] in
the state in which the wheel is not touched. If neutral correc-
tion is OK, the end point correction screen appears. If not
within the correction range, the end point correction screen
will not appear.
2
(Steering wheel travel adjustment)
In the end point correction screen (figure at the right) state,
lightly turn the wheel fully to the left and right and tap the [End
point]. If end point correction is OK, the display returns to the
adjuster screen. If the end point is not within the correction
range, the display does not return to the adjuster screen. In
this case, return to the system menu screen by pressing the
HOME button. If operation cannot be ended normally even
when correction is repeated, please contact the Futaba Ser-
vice Center.
Steering adjustment
3
When finished, return to the System menu screen by pressing the HOME button.
