2
(Changing the operation direction)
Tap [Nor.] or [Rev.] in the direction to set
the direction.
(Changing the the type of operation)
Tap [Nor.] or [Alt.] in the type to set the type.
3
(Steering / trigger switch setting)
It is a function that uses the steering wheel and the throttle
trigger as a switch.
Tap the set value of the position of the
steering switch or trigger switch. Value input
buttons appear on the screen and use the
[+] and [-] buttons to set the switch ON/OFF
position. Alternatively, you can set it by hold-
ing the steering wheel or throttle trigger at
the point where you turn it ON/OFF and tap
the [set]. Fine adjustment is possible with [+]
and [-].
The red range of the bar graph is ON.
4
When finished, return to the Linkage menu screen by pressing the HOME button.
Adjust button
Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Brake rate(ATL)
0~100
Initial value:100
Switch select
