FUTABA 7PX - Throttle Speed

Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Adjustment buttons
- Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
* Throttle trigger position
* Throttle trigger position
* Throttle trigger position
87
Function
Speed
(Preparation)
-Touch the speed mode and select [1].
1
("ALL" turn direction delay adjustment)
Tap the [Turn] side of [All] value button.
Value input buttons appear on the screen.
Use the [+] and [-] buttons to adjust the
turn speed amount.
(Preparation)
-Touch the speed mode and select [2].
1
("Low" and "High" turn direction delay adjustment)
Tap the [Turn] side of [Low] or [High] value
button. Value input buttons appear on the
screen. Use the [+] and [-] buttons to adjust
the turn speed amount.
Adjustment method for 1 Speed
Adjustment method for 2 Speed
2
("ALL" return direction delay adjust-
ment)
Tap the [Return] side of [All] value but-
ton. A warning is displayed saying "Re-
turn speed will be slow. Please be careful.".
If you want to use the return, tapped [Close].
Value input buttons appear on the screen.
Use the [+] and [-] buttons to adjust the re-
turn speed amount.
3
When finished, return to the Racing menu screen by pressing the HOME button twice.
1001
Servo operation is delayed.
1001
Servo operation is delayed.
1001
Servo operation is delayed.
Speed range
1~100
Initial value :
100, there is no delay.
Speed range
1~100
Initial value :
100, there is no delay.
Speed range
High :1~100
Low :1~100
Initial value :
100, there is no delay.
