Operators and Technicians Manual
2006 – 2013 FutureLogic, Incorporated. All Rights Reserved. MNL Page 18 04/29/2013
MNL-000032 REV.D
Appendix A Technical Specifications
This appendix identifies the general specifications of the printer.
These units are to be supplied by Listed or IEC Certified Power Supplies,
rated 24 VDC, minimum 2.7 A, marked "Class 2" or "LPS". (4.0A peak with
Paper Low, Paper Out, Printer Drawer Open, Ticket Taken, Ticket Jam, Ticket
in Chute, Black Mark
(Includes a Host Controllable Buzzer)
90mm/Second (3.5”/Second)
62mm (true near-edge printing)
Interchangeable, 600, 900 Ticket Tray
Application in Memory is Reprogrammable (via Flash BIOS)
Full Page Mode Printing (Simultaneous 4 Orientation Printing:
0°, 90°, 180°, 270°)
Line and Box Draw Printer Resident
Bitmap Graphics
Printer Resident (Stored in Flash) Graphics
Direct Thermal, Top Coated, Fanfolded and Perforated
66mm W x 156mm L
4.5 mil, 1 Color/2 Colors
Two High Current Ticket Printing Bezel Control Ports
4 LED Indicators, Paper Advance Button
Allows for Printer Upgrades via USB Download or RS232 Main port
Max. continuous feed of 1200 tickets with 8-second delay between tickets
8Mb; Stores hundreds of clip art objects & thousands of graphic templates
Red on Black and Blue on Black are available. Other colors can be supported
as the print media becomes available. Color selection is controlled through
