Operators and Technicians Manual

MNL-000032 REV.D

Appendix C Part Numbers – Printer/Spares

This appendix provides the part number and description of the GEN2 Universal (PSA-66-ST2RU)

printer and spare parts.

Printers – P/N

Description

220-00086-300

GEN2 Universal Printer (RoHS)

PSA-66-ST2RU

USB, RS232, Future GSA

Compliant*

RoHS Versions—Look

for either of these

labels:

Spares – P/N

Description

370-00015-100

Base RoHS

370-00170-100

Bottom Chute RoHS

150-00176-100

Cable, USB-RS232, 14 pin RoHS

150-00013-100

Cable, Evaluation, RS232, 14 pin RoHS

150-00164-100

Cable, GDS Adaptor
