Operators and Technicians Manual

MNL-000032 REV.D

Appendix E Regulatory & Compliance

The printer described in this manual is in compliance with all applied CE

standards.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.
