6. Press the cover clip
in the arrowed direction
and take out the cover ①.
7.
Press the filter element cover clip in the
arrowed direction, and take out the filter
element cover ①.
8. Take out the A/C filter ②. Tap the A/C filter to
remove the dust.
9. Refit the A/C filter as per the reverse steps.
NOTE
• Because the fiber layer on the back of the
A/C filter can not be blown with an air gun,
it can not be cleaned and needs to be
replaced in time after getting dirty.
• Since the A/C filter is
material, it shall not be washed with water.
Otherwise, dust will accumulate and form
clots, which will cause decreased air
volume of A/C or even blockage.
6. In-service Maintenance
