GAC GA8 - Page 235

No.
Rated
value
Feature/par
t
EF01 150A Alternator/battery
EF02 80A Electronic power steering control unit
EF03 80A Instrument panel PDU
EF04 60A Radiator fan relay
EF05 40A ACC relay
EF06 — —
EF07 — —
EF08 40A Blower relay
EF09
40 A/60
A
Electronic stability and parking control module
EF10 50A Instrument panel PDU
EF11 40A Electronic stability and parking control module
EF12 30A Starter relay 1
EF13 30A IG1 relay
EF14 15A Amplifier module*
EF15 20A Right front seat connector A
EF16 15A Amplifier module*
EF17 7.5A A/C compressor relay
EF18 20A Left front seat connector A
EF19 20A Right front seat connector A
EF20 20A Fuel pump relay
EF21 30A Wiper relay/wiper speed control relay
EF22 7.5A Brake switch/engine control unit
No.
Rated
value
Feature/part
EF23 15A Horn relay
EF24 15A Automatic transmission control unit
EF25 — —
EF26 15A High beam relay
EF27 10A PCV heater relay
EF28
Shorting
link
Low beam relay
EF29
Shorting
link
Main relay
EF30 10A
Electronic thermostat/relief valve/variable cam timing (exhaust
end)/variable cam timing (intake end)/canister solenoid
valve/CSV
EF31 20A Ignition coil 1/ignition coil 2/ignition coil 3/ignition coil 4
EF32 15A Engine control unit/fuel pump relay
EF33 10A
Starter relay 1/starter relay 2/A/C compressor relay/radiator fan
relay/front oxygen sensor/rear oxygen sensor
EF34 10A Left front combination lamp
EF35 10A Right front combination lamp
EF36 7.5A Engine control unit
EF37 10A PCV heater relay
ER01 — Wiper relay
ER02 — Wiper speed control relay
ER03 — Fuel pump relay
ER04 — PCV heater relay
ER05 — —
229
8. Accident Handling
