GAC GA8 - Page 50

Number
Indicator
Designation
Color
Function
15
Left turn signal and hazard warnin
g
indicator lamp
Green
When the left turn signal indicator lamp flashes alone, it indicates that the left
turn signal lamp of the car is on. When the hazard warning lamp switch is
pressed, the left / right turn signal indicator lamps and all turn signal lamps
outside the car will flash simultaneously.
16
Electric park brake (EPB
) status
indicator lamp
Red
If the red indicator lamp comes on, it indicates that the EPB is applied.
If the red indicator lamp flashes, it indicates that the EPB is engaged partially
or faulty.
Green
If the green indicator lamp comes on, it indicates that the EPB is activated.
17
Electric park brake (EPB) fault
indicator lamp
Yellow
If the yellow indicator lamp comes on, it indicates that the EPB system is
faulty.
If the yellow indicator lamp flashes, it indicates that the EPB is in the service
mode.
18
Parking brake and brake system
indicator lamp
Red
If the red indicator lamp comes on, it indicates that the brake fluid is too low or
the electronic brake force distribution (EBD) system is faulty.
19
Electronic stability program (ESP)
indicator lamp
Yellow
If the yellow indicator lamp comes on, it indicates that the ESP is faulty.
If the yellow indicator lamp flashes, it indicates that the ESP is working.
20
ESPOFF indicator lamp
Yellow
If the yellow indicator lamp comes on, it indicates that the ESP is off.
21
Anti-lock braking system (ABS)
indicator lamp
Yellow
If the yellow indicator lamp comes on, it indicates that the ABS or HHC system
is faulty.
22
Transmission fault indic
ator lamp Yellow
If the yellow indicator lamp comes on, it indicates that the transmission system
is faulty.
If the yellow indicator lamp flashes, it indicates that the transmission fluid
temperature is high.
23
Tire pressure monitoring system
(TPMS) indicator lamp
Yellow If the yellow indicator lamp comes on, it indicates that the TPMS is faulty.
24
Electric power steering (EPS)
indicator lamp
Yellow
If the yellow indicator lamp comes on, it indicates that the EPS system is
faulty.
25
Front passenger seat belt indicator
lamp
Red
If the red indicator lamp comes on, it indicates that the front passenger’s seat
belt is not fastened or the system is faulty.
26
Driver’s seat belt indic
ator lamp Red
If the red indicator lamp comes on, it indicates that the driver’s seat belt is not
fastened or the seat belt system is faulty.
44
4. Operation of Systems and Equipment
