Continuative information
G&D DVIVision · 35
DDC transmission with cache function
The DVIVision system supports Enhanced-DDC (Enhanced Display Data Channel) to
read out the data from the monitor that is connected to the computer module
(DVIVision-CON) and transmit them to the computer. This data includes informa-
tion regarding the preferred resolution and the supported monitor frequencies.
A cache function is integrated in the system so that the computer that is connected
to the computer module (DVIVision-CPU) has access to the actual capabilities of
the remote monitor already during the boot process. Even if the computer module
or the user module are turned off or if the devices are not interconnected, the proper
-
ties of the most recently connected monitor or a default data block are provided in
the DVIVision system.
The DDC information of the monitor are basically transmitted one-to-one. In case,
the DVIVision system determines that the display cannot be read without errors or
that the entries are invalid, the information are completed or corrected
.
1360 x 768 49,892 Hz 69,000 MHz 39,564 kHz
59,799 Hz 84,750 MHz 47,720 kHz
1440 x 480 60,000 Hz 54,000 MHz 31,500 kHz
1440 x 576 50,000 Hz 54,000 MHz 31,250 kHz
1440 x 900 60,000 Hz 106,472 MHz 55,920 kHz
1400 x 1050 60,000 Hz 122,614 MHz 65,220 kHz
1600 x 900 60,000 Hz 118,998 MHz 55,920 kHz
1600 x 1024 60,000 Hz 136,358 MHz 63,600 kHz
1600 x 1200 60,000 Hz 162,000 MHz 75,000 kHz
1680 x 1050 60,000 Hz 147,136 MHz 65,220 kHz
1920 x 1080 50,000 Hz 148,500 MHz 56,250 kHz
60,000 Hz 148,500 MHz 67,500 kHz
1920 x 1200 59,950 Hz 154,000 MHz 74,038 kHz
Display modes that support interlace are not supported by the DVIVision system.
Active resolution Refresh rate Pixel rate Line frequency
Table 3: Exemplary listing of some resolutions
