The expansion DVI-Power
40 · G&D DVIVision
The expansion DVI-Power
The expansion DVI-Power is provided for the variants DVIVision-AR and -ARU to
control the buttons
ATX-Power and Reset of the computer at the remote console.
Scope of delivery
The scope of delivery of DVI-Power expansion includes the following items:
 G&D Power Card (slot card for installing in the computer)
 connection cable to connect G&D Power Card and computer module
 single-sided ready-made cable for connecting a panel to the user module
 2 x two-pole connection cable (0,4 metres)
 2 x two-pole extension cable (0,4 metres)
Functionality
The remote control of both the ATX-Power and the Reset function is carried out
through a panel with two buttons. The panel is installed at the remote console.
The panel is connected to the system through a four-pole modular socket on the
back panel of the user module (DVIVision-CON). The connection cable that is pro
-
vided in the scope of delivery has to be fixed to the panel (see Allocating the connection
cable for the panel on page 43).
The panel for the operation of DVI-Power is not included in the scope of delivery
of DVI-Power and has to be build by an expert.
