Status displays
G&D DVIVision · 37
CPU Video on The incoming video signal of the computer
is being properly received.
blinking No stable video signal is being received or
its quality is insufficent to be processed by
the system.
K/M on The CPU input (PS/2 or USB) is active and
ready for operation. A local keyboard was
found.
off No voltage of the PS/2 interface or the
USB bus.
blinking The CPU input (PS/2 or USB) is active and
ready for operation. A local keyboard was
not found.
flickering Keyboard and mouse inputs are being
transmitted to the computer. The rhythm of
the flickering is determined by the inputs of
the user.
flashing The USB input of the computer module
(DVIVision-CPU) is supplied with voltage.
The computer is not (yet) ready for operation.
Range LED Status Meaning
Table 4: Status displays at the computer module (DVIVision-CPU)
