IMPORT
IMPORT
ANT!
ANT!
Input: AC230V +/-10% ~50Hz 125mA Max. 35W Max
Nominal Temp Range: 0 - 50°C
Gardtec 800 Series Metal Versions
For Indoor Use Only
Gardtec 800 Series Plastic Versions
For Indoor Use Only
This equipment is intended only for use as a Security Alarm Control Panel. Adequate ventilation
away from heat and humidity must be provided. The unit must be fixed securely to a non-
flammable surface using suitable fixings.
All mains wiring must conform to the relevant IEEE wiring regulations (or appropriate
international regulatory standards). See Mains Supply Connection section within this manual for
more detailed instructions.
All wiring must be protected from sharp or jagged edges.
All Low voltage (alarm) wiring must be to the appropriate international regulatory standards and
comply to good wiring practice. Low voltage wiring should not be able to touch mains wiring.
Replacement fuses should be of the same type and rating conforming to IEC 127.
The maximum current draw from the unit for all output combinations must not exceed the
rated output. Please see note:
*Power Supply Rating (Page 172)
.
The unit is intended for use with a suitable re-chargeable lead acid battery permanently
connected to the appropriate terminals.
Battery Fuse
An in-line Battery Fuse has now been incorporated into this product. The fuse rating is 2 Amp Anti-Surge. The fuse holder
is spring loaded, therefore you should ensure that the battery lead is not under tension in order to maintain a good connec-
tion between the fuse and the holder.To change the fuse push the two halves of the holder together and twist
anti-clockwise. Please ensure correct battery charge on completion of the installation and during each service visit.
All documentation and manuals must be thoroughly read by suitably qualified installation
personnel prior to installation.
The unit has no user serviceable parts inside. Internal access should only be by suitably
qualified personnel.
Gardtec 800 Series Metal Versions
The unit must be Earthed. It is the responsibility of the installation engineer to ensure that the
earth connection to the unit lid is good on completion of the installation or after service.
Gardtec 800 Series Plastic Versions
Provision is provided for an earth connection within the mains input connector block, this con-
nection is for protection of the wiring only and is not functional for the unit.
PR5892 Rev11 800 Series Eng Ref 15.qxd 16/11/2006 11:20 Page 2
