2SYSTEM OVERVIEW
Codes
The Gardtec 872 is capable of accepting up to 99 user codes (15 for 800/816) plus 1
engineer code. Each of the user codes is allocated a code type (with the exception of
user 1 that is always Master) at the time the code is programmed. Code types plus
engineer that are available are:
Code Type (872) Code Type (800/816)
Cleaner Set Only
Area 1 Main
Area 2 User
Area 3 Master
Area 4 Cleaner (816 only)
Area 5
Area 6
Area 7
Main 1
Main 2
Main 3
Main 4
Main 5
Main 6
Main 7
Control
Set Only
Main User
Group Master
Group Main
Group Area
Master
Default Master User Code BS / EN2 5678 EN3 005678
Default Engineer Code BS / EN2 1234 EN3 001234
Note: User 1 will always be Master Level.
Note: For EN3 installations, User Codes and Engineer Codes MUST
be six
digits in length.
Note: 800/816 have no area facilities.
Note: 800 series control panels can only be programmed using LCD KEYPAD
.
Page 4
