Page 160
Programming Point ID Protocol
For the purpose of programming PID, it is assumed that the STU Adaptor has
been left in the OFF state.
1) Enter into Engineer Mode
To do this follow Steps 1 to 4 on page 79
With the display showing:-
2) Press No five times. The display will show:-
3) Press Yes. The display will show:-
4) Press Yes. The display will show:-
5) Press No until the display shows:-
6) Press Yes. The display will show:-
7) Press Yes. The display will show:-
Program . . . . _ _ _
Zones ?
Program . . . . _ _ _
Digicom ?
Program Digicom
Type or Test
Digicom Type . . . .
= None
Digicom Type . . . .
> Mod + PID
STU Adaptor
=Off
STU Adaptor O/P
=Pos
PR5892 Rev11 800 Series Eng Ref 15.qxd 16/11/2006 11:21 Page 160
To Next Page
