Page 62
Output Types Terminology
There are two groups of outputs types available.
General Outputs. These are available on the following terminals
Detector Reset Terminal
Latch Terminal
On-Board Relay Terminals (com, N/O, N/C)
PGM 3 Terminal (Strobe Terminal)
Optional Output Cards 872 (max 4 cards each having 4 changeover relays)
When programming these outputs and you press no to the current setting the display
will show:-
872 Only
At this point choose if you require the output to be allocated to Area 1 - 7 or All Areas
or Any Area.
Some General Output Types may be used for triggering Digital
Communicators or RedCare STUs.
Below is given a list of Output Types with a brief description of the option.
Off
Output not used.
Pulse Off
Output is active and will switch for 3 seconds when code is entered.
Pulse On
Output is inactive and will switch for 3 seconds when code is entered.
After Alarm
Will trigger in alarm and stay in alarm until panel has auto rearmed or has been reset.
Walk (Forced Walk Test) (872 only)
When FWT is used, the zones programmed as Walk must be walk tested before the
system will start to set. FWT Mode (option 130) must be programmed to ‘All Sets’ or
‘Full Set Only’ for FWT to operate. A FWT Bypass time is available via option 129. This
allows up to 90 minutes between the system being unset and then set without having
to walk test the system again.
Pulse Set
Will activate for 5 seconds when the panel sets.
Int Sounder
Will activate when panel is in alarm or tamper.
Choose . . 1 - 7 = Area
8 = All 9 = Any
PR5892 Rev11 800 Series Eng Ref 15.qxd 16/11/2006 11:20 Page 62
